Concrete Block Machine | Automatic & Semi-Automatic Block Production Systems

Since 1978, İBAR MAKİNA has been manufacturing high-quality concrete block machines by combining advanced technology with decades of industry experience. We produce fully automatic, semi-automatic and manual concrete block machines, exporting to more than 30 countries worldwide. Our machines are engineered for high efficiency, durability, and long-term performance, and can be customized based on production capacity and automation needs.

What Is a Concrete Block Machine?

A concrete block machine is a production system that compresses a concrete mixture—consisting of sand, gravel, cement, and water—into moulds using vibration and hydraulic pressure. This process allows the production of concrete blocks, interlocking paving stones, and curbstones in different shapes and sizes. Thanks to easy mould replacement, a wide range of products can be manufactured for construction, infrastructure, and landscaping projects.

Types of Concrete Block Machines

1. By Automation Level

• Fully Automatic Concrete Block Machine: PLC-controlled systems that minimize labor and offer high productivity.
• Semi-Automatic Concrete Block Machine: Operator-assisted models providing flexibility and affordable investment.
• Manual Concrete Block Machine: Portable and economical systems suitable for small-scale production.

2. By Production Method

• Stationary Concrete Block Machine: Traditional pallet-based production on a fixed surface.
• Mobile (Egg-Laying) Concrete Block Machine: Machines that lay blocks directly on the ground without pallets.

Fully Automatic Concrete Block Machine Features

Fully automatic systems operate through sensors and a PLC control panel. In an 8-hour shift, they can produce 10,000–18,000 concrete blocks. Main components include:

• Fully automatic concrete block machine
• Automatic mixer
• Front and rear block stacking robots
• Pallet feeding system
• Concrete conveyor and bunker systems

Semi-Automatic Concrete Block Machine Features

Semi-automatic systems operate under operator control and are ideal for investors looking for a lower-cost plant setup. Daily capacity ranges between 4,000–10,000 pieces. Typical system configuration:

• Semi-automatic concrete block machine
• Concrete mixer
• Aggregate bunker
• Conveyor belts

Manual Concrete Block Machine

These compact systems can produce up to 1,000 pieces per day. Aside from vibration, all processes are performed manually. They operate on 220V electricity and offer low operating costs.

Mobile (Egg-Laying) Systems

Unlike stationary systems, mobile machines lay blocks directly on a flat surface without pallets. Although production speed is lower, installation is extremely fast and requires minimal space.

How Does a Concrete Block Machine Work?

The prepared concrete mixture is transferred to the machine’s hopper, poured into the mould, and shaped through vibration and hydraulic pressing. The finished product is transported to the curing area on pallets. After drying, the blocks are removed and the cycle continues.

Concrete Block Machine Prices

Prices vary depending on production capacity, automation level, and optional equipment. Our entry-level model, Block Master 4, offers a daily capacity of 4,000 pieces. Our flagship model, CBM 36 PRO, provides the highest production performance with advanced automation.

Second-Hand Concrete Block Machines

We do not sell second-hand machines directly. However, we help promote our customers’ machines through our social media accounts. Those looking for a second-hand concrete block machine may follow us on Instagram.
