CPM 1600 PRO 300-1600mm Concrete Pipe Machine
Concrete Pipe MachineImage 1 of 9

CPM 1600 PRO 300-1600mm Concrete Pipe Machine

1 / 9
CPM 1600 PRO 300-1600mm Concrete Pipe Machine

CPM 1600 PRO 300-1600mm Concrete Pipe Machine

Production capacity300mm-1600mm

WhatsAppGet a quote now

About the product

The CPM 1600 Pro is a new generation hydraulic concrete pipe machine, designed to meet the diverse production needs of modern infrastructure projects. With this advanced system, users can manufacture concrete pipes ranging from 300 mm to 1600 mm in diameter and pipe lengths from a minimum of 1000 mm up to 2500 mm, based on customer requirements.

Thanks to its robust hydraulic press and fully integrated production design, no overhead crane is required during operation. The system is capable of single, double, or even triple pipe production per cycle, depending on the selected pipe diameter and configuration.

In addition to round pipes, the CPM 1600 Pro also enables the production of:

  • Box culverts up to 1500 × 1500 mm

  • Manhole cones and riser rings up to 1200 mm in diameter

This machine offers high flexibility, exceptional strength, and low maintenance, making it ideal for precast concrete producers seeking maximum efficiency with a single production line.

Product Advantages

  • Wide Production Range with One MachineCapable of producing concrete pipes from Ø300 mm to Ø1600 mm and box culverts up to 1500 × 1500 mm with one system.
  • Manhole Production CapabilityProduces manhole riser rings and conical tops up to Ø1200 mm, expanding production scope beyond standard pipes.
  • Flexible Length OptionsPipe lengths from 1000 mm to 2500 mm can be customized according to customer specifications.
  • Hydraulic Press System – No Crane NeededThanks to its powerful and integrated hydraulic system, production is fully crane-free, reducing installation complexity and factory costs.
  • Multi-Product EfficiencyCan be configured for single, double, or triple production depending on diameter, optimizing output without compromising quality.
  • Heavy-Duty and Low MaintenanceBuilt from high-grade steel and industrial components, ensuring long-term use with minimal downtime.
  • Ideal for Infrastructure ProjectsSuitable for sewer, drainage, utility tunnels, and municipal infrastructure applications.

Product Information

Model
CPM 1600 PRO
Control System
Semi-Automatic / Automatic
Production Capacity
300 mm – 1600 mm
Vibrator Motor Power
30 kW × 2 units
Mortar Hopper Capacity
2.5 m³
Hydraulic Motor Power
22 kW
Mortar Distributor Motor Power
7.5 kW
Screeding Motor Power
7.5 kW
